I/O Semtech SX1262 LoRa IoT Module 5.7km LoRa RF Module

Name: IO Semtech SX1262 LoRa IoT Module 57km LoRa RF Module
Brand: Cansec Wireless
Price: 4.10 USD

Brand Name : Cansec Wireless

Model Number : LR1262NA-A

Place of Origin : Beijing

MOQ : 1000

Price : USD 4.10$ per piece

Payment Terms : T/T

Supply Ability : 2000000 pieces per year

Delivery Time : 5~8 weeks

Packaging Details : Box for 1000 pieces Package size: 40*34*20 cm Gross weight: 5.000 kg

size : 17*24.3*3.4mm

TX Power : 21dBm

RX Sensitivity : -148dBm

Distance : 5.7km

Contact Now

I/O Semtech SX1262 LoRa IoT Module 5.7km LoRa RF Module

Cansec IoT I/O LoRa RF Transceiver Module 868 High Performance LR1262NA-A Semtech-SX1262 Wide Frequency Option LoRa IoT Module

Parameter		Min	Typ	Max	Unit
Operating Voltage		1.8	-	3.7	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	1.5	-	uA
	Receive mode(@DCDC mode)	-	4.9	-	mA
	Transmit Mode	-	120	-	mA
TX Power (For Carrier)		-	20.5	21	dBm
RX Sensitivity (For Lora Modulation)		-	-	-148	dBm
Distance		5.7K			m

The LR1262 module is designed based on SX1262. SX1262 sub-GHz radio transceivers are ideal for long range wireless applications. These devices support LoRa® modulation for LPWAN use cases and (G) FSK modulation for legacy use cases.

Applications
 Smart meters
 Supply chain and logistics
 Building automation
 Agricultural sensors
 Smart cities
 Retail store sensors
 Asset tracking
 Street lights
 Parking sensors
 Environmental sensors
 Healthcare
 Safety and security sensors
 Remote control applications

Features
 LoRa and FSK Modem
 170 dB maximum link budget
 Wide-Supply Voltage: VBAT:1.8 to 3.6V
 RF output up to +21 dBm
 Programmable bit rate up to 62.5 kbps LoRa and 300 kbps FSK
 Integrated DC-DC converter and LDO
 High sensitivity: down to -148 dBm
 88 dB blocking immunity at 1 MHz offset
 Co-channel rejection of 19 dB in LoRa mode
 Fully integrated synthesizer with a resolution of 61 Hz
 FSK, GFSK, MSK, GMSK and LoRa modulation
 Built-in bit synchronizer for clock recovery
 Automatic Channel Activity Detection (CAD) with ultra-fast AFC
 Regular crystals and TXCO crystals are optional
 Preamble detection
 Package and Operating Conditions:
 3.4 mm Pitch, 17 mm×24.3mm Stamp Package for Easy Assembly and Low-Cost PCB Design
 Operating Temperature Range: -20℃ to +70℃




I/O Semtech SX1262 LoRa IoT Module 5.7km LoRa RF Module

FAQ

Q1: Are you a factory or trade company?

A1: We are a professional factory with 25 years experience.

Q2: Can you accept OEM/ODM?

A2: Sure, we have rich OEM&ODM experience.

Q3: Do you have quality assurance?

A3; Each of our products has undergone quality testing and has two years of free after-sales service.
